An Experiment with Checking the glibc Library

Feb 26 2014
Author:

We have recently carried out an experiment with checking the glibc library by PVS-Studio. Its purpose was to study how good our analyzer is at checking Linux-projects. The basic conclusion is, not much good yet. Non-standard extensions used in such projects make the analyzer generate a huge pile of false positives. However, we have found some interesting bugs.

0237_glibc/image1.png

glibc

glibc - is the GNU Project's implementation of the C standard library. Originally written by the Free Software Foundation (FSF) for the GNU operating system.

Released under the GNU Lesser General Public License, glibc is free software.

The description is taken from the Wikipedia article: glibc.

Not long ago, the release of a new version of the glibc library was announced. It prompted us to check this library with our analyzer PVS-Studio. Unfortunately, I was busy with another task for the last two weeks and got the opportunity to write the article about that check only now. I was actually engaged in carrying out a thorough comparison of several static analyzers and then writing a large article about the results of that comparison. This undertaking is very important for us because people are constantly asking about the differences between our analyzer and Cppcheck and Visual Studio 2013's static analyzer. So glibc (glibc-2-19-90) had to wait a while before I could finally get down to it.

We were not expecting to find anything terrible there - and we haven't. The glibc library is very high-quality and it is regularly checked by many analyzers, among which are at least the following ones:

  • Coverity;
  • Clang;
  • Cppcheck.

So it would be a large success to find at least one bug in its code.

Difficulties of analysis

Those not familiar with the internal mechanisms and principles of static analysis tools may view them as very simple utilities. It's a mistake. These are very complex programs.

There are tools like RATS that may confuse you. If you take a look at RATS' code, you'll see that it merely searches for certain function names in files. Tools like that are called static code analyzers too, but their job is actually very far from what real static code analyzers do. Static analysis has nothing to do with a search with regular expressions [1].

We already mentioned a number of times that a Linux-version of an application is absolutely not the same thing as a recompiled executable module [2]. There is a huge gulf between an executable module and a ready software product. One of the obstacles one faces when making a Linux-version is the need to support specific extensions and things like that.

An ordinary programmer who has never dealt with all those aspects doesn't have a slightest idea of how difficult and huge this work is. For example, take a call of the strcmp() function:

cmpres = strcmp (newp->from_string, root->from_string);

An ordinary programmer doesn't even suspect which terrible code this single line will turn into after the preprocessing and which non-standard extensions will be used in it. Particularly in this case, the line above turns into the following stuff:

cmpres = __extension__ ({ size_t __s1_len, __s2_len;
  (__builtin_constant_p (newp->from_string) &&
  __builtin_constant_p (root->from_string) &&
  (__s1_len = strlen (newp->from_string),
  __s2_len = strlen (root->from_string),
  (!((size_t)(const void *)((newp->from_string) + 1) -
  (size_t)(const void *)(newp->from_string) == 1) ||
  __s1_len >= 4) &&
  (!((size_t)(const void *)((root->from_string) + 1) -
  (size_t)(const void *)(root->from_string) == 1) ||
  __s2_len >= 4)) ?
  __builtin_strcmp (newp->from_string, root->from_string) :
  (__builtin_constant_p (newp->from_string) &&
  ((size_t)(const void *)((newp->from_string) + 1) -
  (size_t)(const void *)(newp->from_string) == 1) &&
  (__s1_len = strlen (newp->from_string), __s1_len < 4) ?
  (__builtin_constant_p (root->from_string) &&
  ((size_t)(const void *)((root->from_string) + 1) -
  (size_t)(const void *)(root->from_string) == 1) ?
   __builtin_strcmp (newp->from_string, root->from_string) :
  (__extension__ ({ const unsigned char *__s2 =
  (const unsigned char *) (const char *) (root->from_string);
  int __result = (((const unsigned char *) (const char *)
  (newp->from_string))[0] - __s2[0]);
  if (__s1_len > 0 && __result == 0) {
  __result = (((const unsigned char *) (const char *)
  (newp->from_string))[1] - __s2[1]);
  if (__s1_len > 1 && __result == 0) { __result =
  (((const unsigned char *) (const char *)
  (newp->from_string))[2] - __s2[2]);
  if (__s1_len > 2 && __result == 0)
  __result = (((const unsigned char *)
  (const char *) (newp->from_string))[3] -
  __s2[3]); } } __result; }))) :
  (__builtin_constant_p (root->from_string) &&
  ((size_t)(const void *)((root->from_string) + 1) -
  (size_t)(const void *)(root->from_string) == 1) &&
  (__s2_len = strlen (root->from_string), __s2_len < 4) ?
  (__builtin_constant_p (newp->from_string) &&
  ((size_t)(const void *)((newp->from_string) + 1) -/
  (size_t)(const void *)(newp->from_string) == 1) ?
  __builtin_strcmp (newp->from_string, root->from_string) :
  (- (__extension__ ({ const unsigned char *__s2 =
  (const unsigned char *) (const char *) (newp->from_string);
  int __result = (((const unsigned char *) (const char *)
  (root->from_string))[0] - __s2[0]);
  if (__s2_len > 0 && __result == 0) { __result =
  (((const unsigned char *) (const char *)
  (root->from_string))[1] - __s2[1]);
  if (__s2_len > 1 && __result == 0)
  { __result = (((const unsigned char *)
  (const char *) (root->from_string))[2] -
  __s2[2]); if (__s2_len > 2 && __result == 0)
  __result = (((const unsigned char *) (const char *)
  (root->from_string))[3] - __s2[3]); } } __result; })))) :
  __builtin_strcmp (newp->from_string, root->from_string))));
});

The analyzer is not ready for such a turn-up and starts generating silly false positives on such constructs.

Let me explain this point about false positives by a simpler example. Assume we have the following line of code:

assert(MAP_FAILED == (void *) -1);

The assert() macro expands into the following fragment:

((((void *) -1) == (void *) -1) ? (void) (0) :
  __assert_fail ("((void *) -1) == (void *) -1",
    "loadmsgcat.c", 840, __PRETTY_FUNCTION__));

The PVS-Studio analyzer generates a false positive on the comparison (((void *) -1) == (void *) -1):

V501 There are identical sub-expressions to the left and to the right of the '==' operator: ((void *) - 1) == (void *) - 1 loadmsgcat.c 840

There is nothing to be surprised at. We have already been through all that stuff when adapting our tool for applications built with Visual C++. There is quite a lot to wonder at there, too. It takes you much time and effort to teach the analyzer to understand all those nuances. You have to teach it to understand that it is dealing with the macro "assert" which is harmless and whose job is but to check that the MAP_FAILED macro equals "(void *) -1". We have already done all that for Visual C++, but not for Linux.

It is teaching the analyzer to correctly handle such constructs that makes up the hugest part of work on supporting other compilers. This work is invisible to others, but it really requires you to thoroughly investigate, support and test all the nuances of the compiler and standard libraries.

I've just slightly opened this door to Hell for you to peek in. I'm going to write a series of articles soon to show all the difficulties of static analysis tools' development. Sure you'll like them.

Suspicious code fragments found in the glibc library

Although glibc is tested by many tools, we still have managed to find a few interesting bugs. Let's take a look at them.

A strange expression

char *DCIGETTEXT (....)
{
  ....
  /* Make CATEGORYVALUE point to the next element of the list. */
  while (categoryvalue[0] != '\0' && categoryvalue[0] == ':')
    ++categoryvalue;
  ....
}

V590 Consider inspecting this expression. The expression is excessive or contains a misprint. dcigettext.c 582

The condition can be shortened:

while (categoryvalue[0] == ':')

Perhaps there is no error here and the first part of the (categoryvalue[0] != '\0') condition is simply redundant. But I suspect the error is real and the code should look like this:

while (categoryvalue[0] != '\0' && categoryvalue[0] != ':')

Dereferencing a pointer before checking it

This fragment is not necessarily unsafe - perhaps the pointer can never be null. But I should mention it anyway:

static enum clnt_stat
clntraw_call (h, proc, xargs, argsp, xresults, resultsp, timeout)
     CLIENT *h;
     u_long proc;
     xdrproc_t xargs;
     caddr_t argsp;
     xdrproc_t xresults;
     caddr_t resultsp;
     struct timeval timeout;
{
  struct clntraw_private_s *clp = clntraw_private;
  XDR *xdrs = &clp->xdr_stream;
  ....
  if (clp == NULL)
    return RPC_FAILED;
  ....
}

V595 The 'clp' pointer was utilized before it was verified against nullptr. Check lines: 145, 150. clnt_raw.c 145

In the same file, not far from this piece, there is a similar defect: V595 The 'clp' pointer was utilized before it was verified against nullptr. Check lines: 232, 235. clnt_raw.c 232

Dangerous optimization (a vulnerability)

char *
__sha256_crypt_r (key, salt, buffer, buflen)
     const char *key;
     const char *salt;
     char *buffer;
     int buflen;
{
  ....
  unsigned char temp_result[32]
  ....
  memset (temp_result, '\0', sizeof (temp_result));
  ....
  .... // temp_result not used further on
}

V597 The compiler could delete the 'memset' function call, which is used to flush 'temp_result' buffer. The RtlSecureZeroMemory() function should be used to erase the private data. sha256-crypt.c 385

The compiler is allowed to remove the call of the memset() function when compiling the Release version. Well, it is actually obliged to do so for the sake of optimization. Since the 'temp_result' buffer is not used anywhere after calling the memset() function, the function call itself is not needed too.

This is a vulnerability because the private data will not be erased. The memset() function should be replaced with a more appropriate one. The analyzer suggests RtlSecureZeroMemory(), which is absent in Linux of course. But there are other alternatives.

The same defect: V597 The compiler could delete the 'memset' function call, which is used to flush 'temp_result' buffer. The RtlSecureZeroMemory() function should be used to erase the private data. sha512-crypt.c 396

Undefined behavior

One might expect the glibc library's code to be written in such a way as to provide maximum portability. However, there are quite a lot of shift constructs in it, which can't be safe from the viewpoint of portability.

This is what the C language standard has to say about shifts:

The integer promotions are performed on each of the operands. The type of the result is that of the promoted left operand. If the value of the right operand is negative or is greater than or equal to the width of the promoted left operand, the behavior is undefined.

The result of E1 << E2 is E1 left-shifted E2 bit positions; vacated bits are filled with zeros. If E1 has an unsigned type, the value of the result is E1 * 2 pow E2, reduced modulo one more than the maximum value representable in the result type. If E1 has a signed type and nonnegative value, and E1 * 2 pow E2 is representable in the result type, then that is the resulting value; otherwise, the behavior is undefined.

5 The result of E1 >> E2 is E1 right-shifted E2 bit positions. If E1 has an unsigned type or if E1 has a signed type and a nonnegative value, the value of the result is the integral part of the quotient of E1 / 2 pow E2. If E1 has a signed type and a negative value, the resulting value is implementation-defined.

It follows from this text that it is illegal to shift negative numbers. However, it is a very common operation in the glibc library.

An example of left shift:

static void init_cacheinfo (void)
{
  ....
  count_mask = ~(-1 << (count_mask + 1));
  ....
}

V610 Undefined behavior. Check the shift operator '<<. The left operand '-1' is negative. cacheinfo.c 645

An example of right shift:

utf8_encode (char *buf, int val)
{
  ....
  *buf = (unsigned char) (~0xff >> step);
  ....
}

The "~0xff" expression is of the 'int' type and equals -256.

Below is a list of all the code fragments with incorrect shift operations:

  • strxfrm_l.c 68
  • clock_nanosleep.c 38
  • ifaddrs.c 786
  • xdr_intXX_t.c 35
  • xdr_intXX_t.c 41
  • private.h 327
  • private.h 331
  • zic.c 696
  • zdump.c 212
  • zdump.c 216
  • timer_create.c 47
  • timer_create.c 49
  • loop.c 331
  • loop.c 437
  • mktime.c 207
  • mktime.c 208
  • mktime.c 211
  • mktime.c 212
  • mktime.c 230
  • mktime.c 298
  • mktime.c 298
  • ld-collate.c 298

Using an uninitialized variable

static int send_vc(....)
{
  ....
  int truncating, connreset, resplen, n;
  ....
  #ifdef _STRING_ARCH_unaligned
    *anssizp2 = orig_anssizp - resplen;
    *ansp2 = *ansp + resplen;
  #else
  ....
}
V614 Uninitialized variable 'resplen' used. res_send.c 790

Incorrect string formatting

In some fragments, '%u' is used to print signed variables, and in some other fragments, '%d' is used to print unsigned variables. These are trifles, of course, but they are worth mentioning.

For example:

typedef unsigned int __uid_t;
typedef __uid_t uid_t;

int
user2netname (...., const uid_t uid, ....)
{
  ....
  sprintf (netname, "%s.%d@%s", OPSYS, uid, dfltdom);
  ....
}

V576 Incorrect format. Consider checking the fourth actual argument of the 'sprintf' function. The SIGNED integer type argument is expected. netname.c 51

Other defects of this kind:

  • Consider checking the second actual argument of the 'printf' function. The SIGNED integer type argument is expected. locarchive.c 1741
  • Consider checking the fourth actual argument of the 'printf' function. The SIGNED integer type argument is expected. locarchive.c 1741
  • Consider checking the fifth actual argument of the 'fprintf' function. The SIGNED integer type argument is expected. res_debug.c 236
  • Consider checking the third actual argument of the 'sprintf' function. The UNSIGNED integer type argument is expected. inet_net_ntop.c 134
  • Consider checking the fourth actual argument of the 'sprintf' function. The SIGNED integer type argument is expected. ns_print.c 500
  • Consider checking the fifth actual argument of the 'sprintf' function. The SIGNED integer type argument is expected. ns_print.c 500
  • Consider checking the third actual argument of the 'sprintf' function. The SIGNED integer type argument is expected. ns_print.c 572
  • Consider checking the fourth actual argument of the 'sprintf' function. The SIGNED integer type argument is expected. ns_print.c 572
  • Consider checking the fifth actual argument of the 'sprintf' function. The SIGNED integer type argument is expected. ns_print.c 572
  • Consider checking the third actual argument of the 'sprintf' function. The UNSIGNED integer type argument is expected. ns_print.c 628
  • Consider checking the fourth actual argument of the 'sprintf' function. The UNSIGNED integer type argument is expected. ns_print.c 628
  • Consider checking the fifth actual argument of the 'sprintf' function. The UNSIGNED integer type argument is expected. ns_print.c 628
  • Consider checking the third actual argument of the 'sprintf' function. The SIGNED integer type argument is expected. ns_print.c 645
  • Consider checking the third actual argument of the 'sprintf' function. The UNSIGNED integer type argument is expected. ns_print.c 685
  • Consider checking the second actual argument of the 'printf' function. The SIGNED integer type argument is expected. nis_print.c 209
  • Consider checking the second actual argument of the 'printf' function. The SIGNED integer type argument is expected. sprof.c 480

Conclusion

We should admit that we made a wrong choice for the experiment with testing our analyzer on code from the Linux world - the glibc project is just too high-quality. :) There are too few worthy defects to make the article interesting. But anyway, there are many other well-known and interesting projects under Linux waiting to be tested by PVS-Studio to demonstrate its capabilities.
